AMBERJET™ UP6150 Ion Exchange Resin | Dow/Rohm and Haas Uniform Particle High-Capacity Resin
Product Overview
AMBERJET™ UP6150 is a high-performance uniform particle strong acid cation exchange resin from Rohm and Haas, a brand of DowDuPont. Utilizing advanced Uniform Particle Size (UPS) technology, it offers higher exchange capacity, superior kinetic performance, and more stable pressure drop characteristics. It is specifically designed for ultrapure water, electronic-grade high-purity water, condensate polishing, and advanced industrial water treatment systems.
Key Features
• Uniform Particle Size Distribution – Particle uniformity ≥95%, ensuring balanced flow distribution, lower pressure drop, and improved regeneration efficiency.
• High Exchange Capacity – Total exchange capacity ≥2.0 eq/L, with operating capacity 15-20% higher than conventional resins.
• Excellent Mechanical Strength – Superior abrasion resistance with an annual attrition rate below 3%, extending service life.
• Outstanding Chemical Stability – High resistance to oxidation and temperature, suitable for frequent regeneration and high-temperature applications.
• Low Leachables Design – Complies with electronic-grade ultrapure water standards, with TOC leaching ≤50 ppb.
Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Resin Type
|
Strong Acid Cation Exchange Resin (Gel Type)
|
|
Functional Group
|
Sulfonic Acid (-SO₃H)
|
|
Ionic Form
|
H⁺ or Na⁺ (Customizable)
|
|
Total Exchange Capacity
|
≥2.0 eq/L (H⁺ form)
|
|
Moisture Content
|
50-60%
|
|
Uniform Particle Size
|
0.60-0.75 mm
|
|
Uniformity Coefficient
|
≤1.1
|
|
Wet True Density
|
1.18-1.28 g/mL
|
|
Wet Apparent Density
|
0.78-0.88 g/mL
|
|
Maximum Operating Temperature
|
120°C (H⁺ form), 150°C (Na⁺ form)
|
|
pH Operating Range
|
0-14
|
Applications
• Electronics Ultrapure Water – Semiconductor, photovoltaic, and integrated circuit chip cleaning water systems.
• Power Industry – Power plant condensate polishing, boiler feed water softening.
• Pharmaceutical & Biotech – Water for Injection (WFI) pretreatment, purified water systems.
• Chemical & Petrochemical – Process water demineralization, catalytic reaction bed protection.
• Food & Beverage – Softening treatment, desalination of sugar solutions.
Usage Recommendations
-
Pretreatment: New resin should be alternately soaked and rinsed with 4% NaOH and 4% HCl to remove residual monomers and impurities.
-
Loading Method: Wet loading recommended, with 30-50% backwash expansion to remove fine particles.
-
Regeneration Conditions: Regenerate with HCl or H₂SO₄ at 3-5% concentration, flow rate 3-5 BV/h.
-
Operating Flow Rate: Recommended 10-30 BV/h, adjust service cycle based on water quality.
-
Storage Conditions: Store sealed away from light at 5-40°C; avoid freezing or drying.
Packaging
• Standard: 25 L/bag (approx. 18-20 kg), double-layer plastic bag + fiber drum.
• Bulk: 1000 L/IBC tank (can be repacked as needed).
• Custom: 5 L or 10 L sample packages available.
Quality Assurance
✔ Genuine Dow/Rohm and Haas product, each batch with original Certificate of Analysis (CoA).
✔ Complies with NSF/ANSI 61 Drinking Water Safety Standard.
✔ Professional technical selection support and process commissioning guidance provided.
Important Notes
• Avoid direct contact with oxidants (e.g., Cl₂, O₃) to prevent resin degradation.
• Control acid concentration and temperature during regeneration to avoid resin carbonization.
• For long-term idle periods, convert to Na⁺ form and store in 10% NaCl solution.
Power your ultrapure water system with a stable and reliable core medium – AMBERJET™ UP6150 redefines ion exchange efficiency and longevity with uniform particle technology!
